Ottica e portata
Campo visivo
106°~42°
Illuminazione notturna
Infrarosso 40 m
- Diaframma
- P‐iris
- Lunghezza focale
- 3.3 ~ 12mm
- Campo visivo orizzontale
- 106°~42°
- Apertura massima
- F/1.4
- Formato sensore
- 1/2.5″
Termini collegati alla documentazione tecnica:
campo visivo,
criterio di Johnson,
NETD.
Caratteristiche
- 1/2.5″ progressive scan low lux CMOS
- Min. illumination at 0.04 lux
- Triple streams from H.265 and H.264
- Up to 30 fps at 3840 x 2160
- Vandal resistance (IK10)
- Ingress protection (IP66)
- Megapixel varifocal lens
- P-iris lens for auto iris control
- Day and Night function (with removable IR-cut filter)
- Intelligent IR
- Wide Dynamic Range (WDR)
- IR distance up to 40 m (131 ft)
- 3-axis mechanism (pan / tilt / rotate)
- One sensor input and digital output
- Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I, Class 10) for local storage
- DC 12V / PoE (IEEE 802.3af)
- One-way audio
- Defog
- Motion detection
- Tampering alarm
- Face recognition
- Text overlay
- Privacy mask
- IP address filtering
- Recording assigned by GV-Edge Recording Manager (Windows & Mac version)
- Supports iPhone, iPad, and Android
- 3 languages on Web interface
- ONVIF (Profile S) conformant
Registro di responsabilità
- Verificato da
- GVision Italia
- Vulnerabilità aperte
- nessuna
- Immesso sul mercato UE da
- GVision Italia S.r.l.
Le vulnerabilità di questo prodotto sono assegnate e pubblicate da GVision Italia, unica CNA
italiana sotto ENISA Root, nei termini previsti dall’articolo 14 del Cyber Resilience Act.
Come funziona.
Contenuto della confezione
- H.265 Vandal Proof Dome
- Screw x 4
- Screw Anchor x 4
- Audio Wires x 2
- I/O Cable
- Installation Sticker
- Conduit Converter
- PG21 Conduit Connector
- RJ‐45 Connector
- Waterproof Rubber Sets (for RJ-45 Cat.5 and DC 12V / for RJ-45 Cat.6)
- Torx Wrench
- Big Concave Hexagon Wrench
- Small Concave Hexagon Wrench
- Silica Gel Bag
- Sticker (for Silica Gel Bag)
- Ruler
- 8 GB Micro SD Card (MLC, SDHC, Class 10) (The Micro SD Card is preinstalled in the camera)
- Download Guide
- Warranty Card
