Ottica e portata
Campo visivo
180°
- Diaframma
- Fixed
- Lunghezza focale
- 1.2mm
- Campo visivo orizzontale
- 180°
- Apertura massima
- F/2.2
- Formato sensore
- 1/1.7″
Termini collegati alla documentazione tecnica:
campo visivo,
criterio di Johnson,
NETD.
Caratteristiche
- 1/1.7″ progressive scan CMOS
- Triple streams from H.265, H.264 and MJPEG
- Up to 30 fps at 4000 x 3000
- Day and Night function (with removable IR-cut filter)
- Intelligent IR
- Vandal resistance (IK10+ for metal casing)
- Ingress protection (IP67)
- DC 12V / PoE+ (IEEE 802.3at)
- Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I) for local storage
- USB slot for GV-WiFi Adapter or USB hard drive
- One sensor input and one alarm output
- Built-in microphone
- Digital Object Tracking
- Provides 360° and 180° panorama view
- Stereographic projection to reduce the distortion of the image
- Different angle of view accessible by multiple users at the same time
- Playback from any view angle and zoom level
- No mechanical moving parts
- Two-way audio
- Wide Dynamic Range (WDR)
- Low lux enhancement
- 3D noise reduction
- Smart streaming
- Tampering alarm
- Virtual PTZ function
- Auto Pan function
- Privacy mask
- Visual automation
- Text overlay
- 31 languages on Web interface
- ONVIF (Profile S) conformant
- Recording assigned by GV-Edge Recording Manager (Windows version)
- TAICS IoT Cyber Security certified
Registro di responsabilità
- Verificato da
- GVision Italia
- Vulnerabilità aperte
- nessuna
- Immesso sul mercato UE da
- GVision Italia S.r.l.
Le vulnerabilità di questo prodotto sono assegnate e pubblicate da GVision Italia, unica CNA
italiana sotto ENISA Root, nei termini previsti dall’articolo 14 del Cyber Resilience Act.
Come funziona.
Contenuto della confezione
- H.265 Fisheye Camera
- Back Plate
- Plate Screw x 3
- Plastic Screw Anchor x 3
- Torx Wrench
- RJ-45 Connector
- Data Cable
- Terminal Block
- Installation Sticker
- Ruler
- Silica Gel Bag x 2
- Download Guide
- Warranty Card
Documentazione
Accessori compatibili
GV-Mount100
Straight Tube and Junction Box Kit · Dimensions: 200 x 170 x…
GV-Mount101
Straight Tube Kit · Dimensions: 219 x 125 x 332 mm (8.6…
GV-Mount200
Wall Pendant Mount · Dimensions: 225 x 140 x 250 mm (8.9…
GV-Mount203
Junction Box · Dimensions: 315 x 195.5 x 225 mm (12.4 x…
GV-Mount206
Wall Box Mount · Dimensions: 126.5 x 211.3 x 176.85 mm /…
GV-Mount 208-2
Swan Neck Mount · Dimension: 1043 x 519 x 256 mm (41.06…
GV-Mount702
Extension Tube · Four options are available. · Dimensions:Ø 5.4 x 10…
GV-Mount903-1
Dome Housing · Dimensions: Ø 185.5 x 165.3 mm (Ø 7.3″ x…
